Scratch-Resistant
Fire Retardant
Easy to Clean
38Db Sound Insulation
Monoblock System
Water and Moisture Resistant
Atlantis 30 Minute Fire-Resistant Hotel Door with Card Access, VDM-ATLANTIS
This hotel room door model is a professional solution designed for hospitality projects and comes with a 30-minute fire resistance certification. Thanks to its compatibility with card access lock systems, it can be integrated into hotel automation and access control setups. With its complete MDF frame, door leaf and architrave structure, the certified system integrity is maintained, while components such as a smoke seal, automatic drop-down seal (guillotine) and door closer support smoke control and ensure the door closes in a controlled, safe manner.
Case width is one of the most important factors affecting the price, regardless of whether it is aluminum, sheet metal, or composite. The wall thickness must be specified clearly. Since aluminum and sheet metal cases are adjustable, the type of case used will be tailored to the wall thickness you provide.
Typically specified in technical specifications as sheet metal enclosures or aluminum enclosures. The most practical and durable option is the aluminum enclosure, which is resistant to water, moisture, and humidity. If not specifically mentioned in the technical specifications, a composite enclosure may also be a suitable choice.
Since laminate doors are designed as panel doors, they can be adjusted on-site during installation to open in the desired direction. There is no need to specify this explicitly. However, if you are ordering from outside the city and want the door pre-assembled, you can indicate the opening direction in the measurement list.
The wing width can be customized according to the available space. For instance, in areas where a clear passage of 90cm is required, the net width of the wing can be adjusted to 93cm. To ensure accuracy in measurements, it is advisable to provide a technical drawing or precise measurements of the space. If you need assistance with this, feel free to request a team from us. Production can commence once the measurements are agreed upon.
For the door handle options “Stainless Steel L Handle” and “Stainless Steel U-Type Handle”, the lock type can be selected as WC, room, or barrel.
However, if “Child-Safe Classroom Door Handle (Flush, Push-Down Type)” or “Hoppe Handle” is selected, only a barrel (Yale) lock must be used.
For card lock systems, package pricing is provided based on the number of doors and other technical details.
If you plan to use a card lock system, please request a price quotation.
Installation services are available within Istanbul. For installations outside Istanbul, you can request a custom quote or seek assistance from local installers in your area.
Efor Laminat
- OfficialMüşteri Temsilcisi
- Gsm+90(553) 761-3013
- Office+90(538) 483-7461
- Emailinfo@eforlaminat.com
QUICK ACCESS
- You can comment and ask questions
- Bank Account Information?
- Map and Location Information
30-Minute Fire-Resistant Hotel Door Compatible with Card Access (Atlantis Series)
Choosing doors for hotel projects goes beyond aesthetics; critical factors like fire safety, smoke control, access security, and operational continuity depend directly on door performance. The Atlantis series offers a professional hotel door solution designed for guest room entrances, featuring a 30-minute fire resistance certification, compatibility with card lock systems, and a full MDF body construction.
This series is especially favored in high-traffic hospitality facilities aiming to meet fire regulation standards. Thanks to the MDF design of the frame, door leaf, and casing, it maintains structural integrity throughout certification. A key aspect of fire-resistant doors is treating the door as a complete system, not just the leaf. The Atlantis series integrates essential safety components like drop seals, smoke gaskets, and door closers to complete this system.
Technical Structure and Material Integrity
The main advantage of the Atlantis series is delivering the necessary structural integrity for fire resistance and smoke control as a unified door system.
MDF Frame + MDF Door Leaf + MDF Casing
This series uses a consistent material approach:
- Frame: MDF
- Door Leaf: MDF
- Casing: MDF
This uniformity is critical for certification requirements of fire-resistant doors: frame-to-leaf compatibility, predictable expansion behavior, and stable connection points.
Note: Fire-resistant door certification depends not only on materials but also on installation methods and accessory combinations.
30-Minute Fire Resistance (FR30)
A 30-minute fire resistance rating for hotel room doors is a vital safety layer that supports effective evacuation plans. The Atlantis series achieves this by carefully engineering:
- door leaf internal structure,
- frame-to-leaf fitting geometry,
- sealing components,
- accessory selection
to work together seamlessly.
The goal of fire-resistant doors is to delay, during a fire event, the:
- passage of flames,
- transfer of heat,
- spread of smoke,
thereby buying crucial time for corridor and room evacuations.
Smoke Control: Smoke Gasket + Drop Seal System
One of the most dangerous factors in a fire is smoke, which spreads before flames. Therefore, hotel projects require not only fire resistance but also effective smoke sealing.
Smoke Gasket
The smoke gasket around the door:
- minimizes gaps when the door is closed,
- reduces uncontrolled smoke spread into corridors and rooms,
- helps lower panic during fire emergencies.
Drop Seal (Automatic Bottom Seal)
The bottom of the door is typically the weakest point for smoke leakage. The Atlantis series includes a drop seal system that:
- activates automatically when the door closes,
- seals the bottom gap to enhance smoke tightness,
- operates smoothly without floor contact during normal use, ensuring operational convenience.
Secure Closing with Door Closer
Keeping fire doors closed is a key performance requirement. In hotels, heavy use often leads to doors being left open or not fully closed.
The door closer in the Atlantis series:
- ensures controlled closing,
- reduces the risk of doors staying open,
- supports proper latch engagement,
- helps the door fulfill its fire safety function.
This component is crucial for both safety and operational efficiency, resulting in fewer malfunctions, less maintenance, and more reliable use.
Card Lock Compatibility (Hotel-Style Electronic Locks)
The Atlantis series is designed to be compatible with card lock systems commonly used for hotel room entrances, enabling seamless integration with hotel automation.
Benefits of card access integration include:
- controlled room access,
- simplified key management through cards,
- streamlined front desk operations,
- customizable staff access permissions.
Key point: Doors fitted with card locks require precise preparation of lock pockets, strike plates, and frame-to-leaf tolerances. This series is engineered with the technical infrastructure to meet hotel application standards.
Ideal Use Cases for Hotel Projects
The Atlantis fire-resistant hotel door is suitable for:
- Hotel guest room entrances
- Apartment hotel room doors
- Suite room entrances
- Private floor sections
- Staff/service areas (subject to project specifications)
Critical Factor in Certified Systems: Proper Installation
Certification performance depends not only on the product but also on installation quality. Key installation steps include:
- accurate leveling of the frame,
- correct sealing and connection between wall and frame,
- proper adjustment of smoke gaskets and drop seals,
- correctly calibrated door closer closing force.
These steps directly impact consistent performance.
Summary
The Atlantis series offers a fully integrated MDF frame, MDF door leaf, and MDF casing construction with a 30-minute fire resistance certification. It is enhanced with essential features like smoke control (smoke gasket + drop seal) and secure closing (door closer), making it an ideal card access compatible hotel room door solution.
These features not only boost guest safety but also help reduce maintenance needs during heavy use, supporting better control over operational costs in hotel environments.
